Toothbrush Impact Testing Machine ISO 20126

High-precision pendulum impact testing machine for toothbrush durability simulation. Features carbon fiber pendulum, Omron encoder, and bilingual interface. Meets ISO 20126, ASTM D256, & GB/T 1843 standards. Ensure the durability of toothbrushes with this impact testing machine. Evaluate strength and quality to meet industry standards. Improve product reliability and customer satisfaction.
Availability:
Quantity:
Inquire Add to Basket

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
sharethis sharing button

  • GC-YSCJ-2.75

  • Guangce

  • 9031809090

Product Description

Toothbrush Impact Testing Machine


A. Product Introduction

    The Toothbrush Impact Tester is specifically developed to assess the impact toughness of toothbrush and electric toothbrush materials. It features a straightforward design, user-friendly operation, and high-precision measurement. Equipped with a digital display and high-accuracy encoder technology, the instrument ensures excellent stability and a broad testing range. It provides readouts of impact strength and average values, incorporates automatic energy-loss correction, and supports test report printing.

B. Applicable / Reference Standards

  • ISO 180:2000 — Plastics — Determination of Izod impact strength of rigid materials

  • GB/T 1843:2008 — Test method for Izod impact strength of rigid plastics

  • JB/T 8761:1998 — Plastics — Izod impact testing machines

  • ASTM D256-2010 — Standard test methods for determining the Izod pendulum impact resistance of plastics

  • ISO 20126:2012 — Dentistry — Manual toothbrushes — General requirements and test methods


C. Product Features

  • High-precision intelligent controller with LCD display for clear, accurate readings

  • Carbon-fiber pendulum arm for enhanced rigidity, vibration-free operation, and longer service life

  • Imported high-resolution digital encoder for superior angular accuracy and stability

  • Aerodynamic impact hammer and imported bearings to minimize frictional losses

  • Automatic result calculation; stores up to 24 data sets and calculates averages

  • Selectable Chinese/English interface; results in J/m, KJ/m², kg·cm/cm, or ft·lb/in

  • Built-in micro-printer for individual or summary test reports

D. Technical Specifications

Parameter

Specification

Display

Color touch screen (Chinese/English interface)

Angle Sensor Brand & Accuracy

Imported Omron encoder, accuracy to 0.01°

Energy Display Resolution

0.01 J

Impact Velocity

3.5 m/s

Pendulum Energy

2.75 J

Pendulum Angle of Rise

150°

Distance from Pendulum Center to Impact Edge

335 mm

Distance from Impact Edge to Top of Specimen Clamp

55 mm

Radius of Impact Edge

R = 0.8 ± 0.2 mm

Included Angle of Impact Edge

75°

Machine Weight

Approx. 85 kg

Power Supply

AC220V ±10%, 50Hz

Dental Durability Testing Equipment Toothbrush Impact Tester ISO 20126 Testing Equipment pendulum impact tester Toothbrush Durability Test Machine 2.75J Impact Testing Machine Dental Product Testing Equipment
